Dartmouth Stripe (Blackout), Biscuit - Motorised Roller Blind

• The 247 Blackout range comes with a white backing.
• Roller blinds are supplied as standard with a sidewinder control unit. The operation is through a white plastic beaded chain used to raise and lower.
• All blinds are mounted on a strong aluminium tube – 32mm in diameter. We introduce a 40mm tube for larger blinds where necessary.
• All brackets are painted white over metal – 45mm width x 65mm length.
• The bottom finish of the blind will be a straight finish. This will be finished with either a ‘stitched bottom pocket’ or a heat welded seam, with a plastic bottom lathe, dependent on the suitability of the fabric.
• Please note that the cloth width is 3.5 - 4cm narrower than the overall cassette width to allow for the control component. We always manufacture based on full blind width, not fabric width.
• All items are cut to size and will be accurate with working tolerances and variances of +/-5mm.
• All our blinds are manufactured and supplied to be compliant with child safety regulations. As part of this compliance, all control cords and chains will be made to a maximum of 1 metre. If you need to discuss this, please contact us.
• All roller blinds are produced with extra fabric added to the drop ordered.  This is to ensure that there is enough material to conceal the metal tube when the blind is full down/closed.  This is normal and standard practice throughout the industry.

On Standard Roller Finishes, Fixtures & Fittings

• All blinds are mounted on a strong aluminium tube – 32mm in diameter. We introduce a 40mm tube for larger blinds where necessary.
• Choose your chain type, from durable plastic to stylish chrome. The ball will be 4.5mm.
• All brackets are painted white over metal – 45mm width x 65mm length.
• The ball chains are 4.5mm in size.
• The bottom finish of the blind will be a straight finish. This will be finished with either a ‘stitched bottom pocket’ or a heat welded seam, with a plastic bottom lathe, dependent on the suitability of the fabric choice.
• All items are cut to size and will be accurate with working tolerances and variances of +/- 5mm.
• Roller blinds with a width greater than 180cm and a drop greater than 164cm MAY have a horizontal seam due to fabric width / design.
• Cloth width is 3.5— 4cm narrower than the overall bracket to bracket (exact) width to allow for the control components.
• The chain drops come as an endless loop with a safety P clip. The sizes for these are as follows:-

Twist&Fit Roller Blinds

• These blinds are designed as a drill-free, screw-free solution for fitting roller blinds. Brackets are not required, and you can fit these blinds in a matter of seconds.
• Available under the “recess” fitting option only under the relevant products.
• Twist Fit Roller blinds are supplied as standard with a sidewinder control unit. The operation is through a 4.5mm chrome beaded chain used to raise and lower.
• These roller blinds are produced the same way as a standard roller, though unlike roller blinds the tolerance of -5mm is not made for the recess due to the adjustability of the fitting.
• The twist cog can be used to adjust the tension.

On Twist&Fit Roller Finishes, Fixtures & Fittings

• Twist&Fit Unit is made from POM & PEM materials. This provides a durable, moisture-resistant component.
• The Twist End at its largest point (the cog wheel) has a width of 5.1cm | The external pad is 4.1cm width & height. | The distance from the end of the piece to the roller tube is 3.5cm, and when compressed at is smallest is 1.9mm to the tube.
• Sidewinder End is provided with a chain cover. Please do not attempt to remove this cover.
• The sidewinder end at its largest point is 5.1cm width & 6.4cm height.
• Only available on a 32mm diameter tube.
• All items are cut to size and will be accurate with working tolerances and variances of +/- 5mm.
• The bottom finish of the blind will be a straight finish. This will be finished with either a ‘stitched bottom pocket’ or a heat welded seam, with a plastic bottom lathe, dependent on the suitability of the fabric choice.
• Cloth width is 4-4.5cm narrower than the overall bracket to bracket (exact) width to allow for the control components.
  ​
  ​

Motorised Information:

Motorised operation removes the requirement for a chain control. Available on standard and Twist&Fit roller blinds for a smooth, effortless use.

• Rechargeable built-in lithium battery (1500mAh)
• Maximum load capacity: 3kg
• Compatible with 32mm tubes
• Minimum blind width: 500mm
• Quiet operation: under 40dB
• Motor speed: 25rpm
• Lightweight design: 320g
• Operating temperature: -20°C to +55°C
• Charging voltage: DC 5V
